Camera

Camera

Name: camera

Description:

Camera pixel 1920 × 1080 pixel

Camera size 97mm (L) × 41mm (W) × 52mm (H)

Waterproof grade ipx8

Four buttons of the camera are programmable, and the programmable functions are AWB, video recording, zooming out, zooming in, capturing, brightness of light source +

Light source brightness, freezing, hue, noise reduction, dark area improvement, flipping, saturation, contrast, de moire

Power supply 100v-220v, 50 / 60Hz

video signal

3G-SDI

HDMI

DVI-D

Foot function 1 switch programmable, programmable functions are: AWB, video recording, reduction, amplification, snapshot, light source brightness +

Light source brightness, freezing, hue, noise reduction, dark area improvement, flipping, saturation, contrast, de moire

5 user scenarios (standard, user 1, user 2, user 3, user 4), support customization

image processing

Hue (standard - giant shark screen, hue 1 - giant beacon screen, hue 2 - Kaiying screen, hue 3-sony1, hue 4-sony2)

White balance (AWB, ATW, manual R / b configuration)

Digital noise reduction (off, low, medium, high)

Electronic amplification (x1.0 to x5.0)

Electron reduction (x0.5 to x0.9)

Gain (1-10 gears)

Brightness (1-10 gears)

Dark area improvement (off, low, high)

De moire (off, mode 1 - hard mirror, mode 2 - hard mirror, mode 3 - soft mirror)

Image flip (horizontal, vertical, mirrored)

Dual mirror display (3g-sdi / DVI-D access)

Capture resolution 1920x1080, format BMP / jpeg, picture quality low / medium / high / best, support u disk

Recording resolution 1920x1080, format MP4, recording quality low / medium / high / best, support u disk

Communication interface RS-232 × 1

Date time setting support

System language Chinese and English
